*LEVELED * AT4 TRUCKS - LET SEE THEM PICTURE PLEASE

[20AT421]

Perfect thank you!

I clocked the screwdriver so sides matched and I believe it was only half a turn to get there.



AT4 Forum Fav 👍

TORQUE Airbag Suspension Kit for 2019-2024 GMC 1500 - Grab one through Amazon!

[Johnv76]

1inch front peak suspension level, with a 1inch rear peak suspension lift. 285/75 18's "35x11.5" Nitto Ridge Grappler's.



[Clarkie21]

2023



[Clarkie21]

2023



[K80_AT4]

2023



[nabatron]

ReadyLift leveling kit
Icon Alloys Compression 17x8.5 -0 offset
Toyo Open Country ATIII 35x12.5x17
View attachment 6700
View attachment 6700View attachment 6701View attachment 6702View attachment 6703View attachment 6704View attachment 6705View attachment 6706View attachment 6707View attachment 6708

How much poke are you getting with 0 offset?



[DHW]

1inch front peak suspension level, with a 1inch rear peak suspension lift. Still out on a date night with the wife and boy she looks good. 35's coming soon.

View attachment 10089

Did you change the UCAs with those front spacers? Can't seem to get a straight answer as to whether its necessary with only a 1" spacer.



[Johnv76]

Did you change the UCAs with those front spacers? Can't seem to get a straight answer as to whether its necessary with only a 1" spacer.

I did not change out the UCA's. I verified from Peak Suspension that UCA's don't need changed out with the 1 inch level. I also confirmed during install that at full extension of the front suspension that the UCA does not hit the spring, and nothing rubs. Here are some pictures.



[Jimmy23]

ReadyLift leveling kit
Icon Alloys Compression 17x8.5 -0 offset
Toyo Open Country ATIII 35x12.5x17
View attachment 6700
View attachment 6700View attachment 6701View attachment 6702View attachment 6703View attachment 6704View attachment 6705View attachment 6706View attachment 6707View attachment 6708

Nice set up. I take it no issues with clearing the calipers putting on 17” wheels? Did you put on spacers? I want to run 17s but was told I would have issues with calipers.



[OKLAGMCRUISER]

2” front leveling kit by ready-lift, minus the strut spacer that requires spring removal disassembly. 1” wheel spacers, and Venom Power Terra Hunter x/t 305x55r20 on 20x9" stock rims. View attachment 6569View attachment 6570View attachment 6571

Love it...and man it is so good to see a garage of appropriate size to fit your truck into with walking room around it. Newer houses in my area lack garage space of this magnitude.



[Cocoabean]

How much poke are you getting with 0 offset?

There isn't any poke in my opinion. The front sits narrower than the rear, so I added a 6mm spacer in the front to make it look more squared up. It is flush to the top of the fender, and pokes about 1"-1.5" at the bottom due to the fender shape.



[Cocoabean]

Nice set up. I take it no issues with clearing the calipers putting on 17” wheels? Did you put on spacers? I want to run 17s but was told I would have issues with calipers.

The 17's cleared the calipers just fine. You need to be aware of the backspacing for whatever wheel you go with, but the 17's don't have any issues for the height of the caliper. I did add a 6mm spacer up front, but that wasn't for clearance issues. I did it to square up the stance to the rears.



[gemarsh]

Love it...and man it is so good to see a garage of appropriate size to fit your truck into with walking room around it. Newer houses in my area lack garage space of this magnitude.

Welcome.



[cynistersix]

Readylift upper strut spacer and a-arms on the AT4X, 295/60R20 Toyo Open Country A/T on 20x9 +20 Fuel Blitz with Black Gorilla Lugs and Black on Black center caps.



[Jimmy23]

Got the Bilstein 6112s and 5100s put on today. Went with the circlip in the #3 position (1.2” of lift) for the leveled look. Also put on some BDS UCAs.
